snmp3_real_walk
(PHP 4, PHP 5)
snmp3_real_walk — Return all objects including their respective object ID within the specified one
说明
array snmp3_real_walk ( string $host , string $sec_name , string $sec_level , string $auth_protocol , string $auth_passphrase , string $priv_protocol , string $priv_passphrase , string $object_id [, string $timeout = 1000000 [, string $retries = 5 ]] )The snmp3_real_walk() function is used to traverse over a number of SNMP objects starting from object_id and return not only their values but also their object ids.
参数
- host
-
The hostname of the SNMP agent (server).
- sec_name
-
the security name, usually some kind of username
- sec_level
-
the security level (noAuthNoPriv|authNoPriv|authPriv)
- auth_protocol
-
the authentication protocol (MD5 or SHA)
- auth_passphrase
-
the authentication pass phrase
- priv_protocol
-
the privacy protocol (DES or AES)
- priv_passphrase
-
the privacy pass phrase
- object_id
-
The SNMP object id.
- timeout
-
The number of microseconds until the first timeout.
- retries
-
The number of times to retry if timeouts occur.
返回值
Returns an associative array of the SNMP object ids and their values on success or FALSE on error. In case of an error, an E_WARNING message is shown.
范例
Example #1 Using
snmp3_real_walk()
The above will output something like:
<?php
var_export(snmp3_real_walk('localhost', 'james', 'authPriv', 'SHA', 'secret007', 'AES', 'secret007', 'IF-MIB::ifName'));
?>
array (
'IF-MIB::ifName.1' => 'STRING: lo',
'IF-MIB::ifName.2' => 'STRING: eth0',
'IF-MIB::ifName.3' => 'STRING: eth2',
'IF-MIB::ifName.4' => 'STRING: sit0',
'IF-MIB::ifName.5' => 'STRING: sixxs',
)
参见
- snmpwalk() - 从代理返回所有的 SNMP 对象
